| Datasheet | HYD
3000-ES | HYD
3600-ES | HYD
4000-ES | HYD
4600-ES | HYD
5000-ES | HYD
6000-ES |
| Battery Parameters |
| Battery Type | Lithium-ion, Lead-acid |
| Nominal battery voltage | 48V |
| Battery voltage range | 42-58V |
| Battery Capacity | 50-2000Ah |
| Maximum Charging/Discharging Power | 3000W |
| Maximum Charging/Discharging Power | 65A(Programmable) |
| Maximum Discharging Current | 70A(Programmable) |
| Charing curve(Lithium-ion) | BMS |
| Charing curve(Lead-acid) | 3-Stage adaptive with maintenance |
| Depth discharge | Lithium-ion: 0-90% DOD adjustable, Lead-acid:0-50% DOD adjustable |
| Input DC(PV side) |
| Recommended Max. PV input power | 3990Wp | 4790Wp | 5320Wp | 6120Wp | 6650Wp | 7980Wp |
| Max DC power for single MPPT | 2000W | 2400W | 2600W | 2800W | 3000W | 3500W |
| Max. Input voltage | 600V |
| Start-up voltage | 120V |
| Nominal DC Voltage | 360V |
| MPPT operating voltage range | 90-580V |
| MPPT operating voltage range | 90-580V |
| Full power MPPT voltage range | 160V-
520V | 180V-
520V | 200V-
520V | 230V-
520V | 250V-
520V | 300V-
520V |
| MPPT number | 2 |
| Max. Input MPPT current | 12A/12A |
Max. input short circuit current per
MPPT | 15A/15A |
| Qutput AC(Grid side) |
| Rated power | 3000W | 3680W | 4000W | 4600W | 5000W | 6000W |
| Max. AC power | 3000VA | 3680VA | 4000VA | 4600VA | 5000VA | 6000VA |
| Nominal grid voltage | L/N/PE,220Vac,230Vac,240Vac |
| Operation phase | Si ngle(L-N-PE) |
| Max. Input/Output current | 13.7A | 16A | 18.2A | 21.0A | 22.8A | 27.3A |
| AC voltage Range | 180V-276V(According to local standard) |
| Grid Frequency Range | 45HZ-55Hz/54Hz-56Hz(According to local standard) |
| THD | <3% |
| Power factor | 1default(adjustable+/-0.8) |
| Output AC(Emergency Power Supply) |
| EPS rated power | 3000VA |
| Operation phase | Si ngle(L-N-PE) |
| EPS rated voltage, Frequency | 230V,50/60Hz |
| EPS rated current | 13.2A |
| Peak Output Apparent Power | 4000VA,10s |
| THD | <3% |
| Swiich time | 10ms default |
| Efficiency |
| MPPT efficiency | 99.90% |
| Max efficiency of solar Inverter | 97.60% | 97.60% | 97.60% | 97.80% | 97.80% | 98.00% |
| European weighted efficiency | 97.20% | 97.20% | 97.20% | 97.30% | 97.30% | 97.50% |
| Max. Charging eficiency of battery | 94.60% |
| Max. Discharging eficiency of battery | 94.60% |
| Protection |
| PV reverse polarity protection | Yes |
| PV insulation detection | Yes |
| Ground iault monitoring | Yes |
| Over current protection | Yes |
| Over voltage protection | Yes |
| Battery soft start protection | Yes |
| SPD protection | Ⅲ |
| General Data |
| Ambient temperature range | -25℃~+60°C(Above 45℃ Derating) |
| Standby Losses | <10W |
| Topology | High frequency insolation(for bat) |
| DC-Switch | Yes |
| Degree Of Protection | IP65 |
| Allowable Relative Humidity Range | 0—100% |
| Communication | RS485/USB, WiFi/Ethernet/GPRS, SD, CAN 2.0 |
| Protective class | Class I |
| Max. Operating altitude | 2000m |
| Current Sensor Connection | External |
| Noise | <25dB |
| Weight | 20.5kg |
| Cooling | Natura |
| Dimension | 566*394*173mm |
| Display | LCD display |
| Warranty | 5 years or more |
| Standard |
| EMC | EN61000-6-2,EN61000-6-3,EN61000-3-3,EN61000-3-11,EN61000-3-12 |
| Safety standards | IEC62109-1/2,IEC62040-1,IEC62116,IEC61727,IEC-
61683,IEC60068(1,2,14,30) |
| Grid standards | AS/NZS4777VDE V0124-100,V0126-1-1,VDE-AR-N 4105,CE10-
21,EN50549,G83/G59/G98/G99,UTEC15-712-1,UNE206007-1 |
